Processor |
- Intel® Pentium® 4, Celeron® Processor
|
|
Front Side Bus |
|
|
Chipset |
- Intel 845PE North Bridge
- Intel ICH4 South Bridge
|
|
System Memory |
- (2) 184-pin DDR DIMM Sockets (2.5v)
- DDR 333/266/200 ( PC2700/2100/1600)
- Support for up to 2GB
|
|
Expansion Slots |
- (1) AGP 4x, supports 1.5v display
card only.
- (5) PCI (PCI 2.2 compliant)
- (1) CNR
|
|
Onboard IDE |
- (2) ATA 133/100/66 Bus Master IDE
|
|
Onboard FDD |
- (1) Floppy Disk Drive (FDD) Connector (Supports Modes,
1.2/1.44/2.88 mb)
|
|
Onboard Audio |
- 2 Channel Intagrated Audio
- AC'97 CODEC
|
|
Onboard I/O |
- (6) USB 2.0/1.1 (4 Front /2 Rear)
- CD Audio-in Connector
- Auxiliary-In (AUX) Connector
- Wake-on-LAN
- (3) CPU / Power / Chassis FAN connectors
|
