Form Factor

Micro-ATX

Dimensions

244mm x 180mm

Processor

Socket 370 for Intel Pentium III (0.18?0.13? and Intel Celeron (0.18?0.13?

FSB

66MHz, 100MHz or 133MHz

Northbridge Core Chipset

VIA Apollo PLE133T

I/O Chipset

BIOS

2Mb Flash ROM, Award BIOS Support ACPI, PnP, and DMI

Audio Codec

System Memory

2 SDR DIMM Slots.

Supports PC-100 and PC-133 (not PC-66)

Supports a maximum of 1.0GB memory

Expansion Slots

2 PCI Slots

Connectors

PS/2 Keyboard

PS/2 Mouse

Serial Port 1 (COM 1)

Serial Port 2 (COM 2)

Parallel Port (LPT)

Game and Midi Port

Floppy Disk Connector (FDC)

2 IDE Connectors

CD-In Connector

2 Fan Connectors

WOL (Wake-On-LAN) Connector

AUX-In (Auxiliary-In) Connector

IR (Infrared) Connector (Optional)

S/PDIF Connector (Optional)

Hardware Monitoring
