Intel® 815E AGPset

PROCESSOR

Universal socket 370 supports Intel® FC-PGA/FC-PGA2 Pentium® III (CopperMine / Tualatin) or other compatible processors

66/100/133 MHz FSB

AUTO detect CPU voltage

CHIPSET

Intel® 815E AGPset

iTE IT8712F-A I/O and health chip

AC97 codec

MEMORY

Up to 512MB memory size

2 x DIMM sockets

Supports 32/64/128/256/512 MB SDRAM module

SLOT

1 x AGP slot supports 2X/4X mode AGP card or supports AIMM

3 x PCI slots support 33MHz and PCI 2.2 compliant

I/O

2 x UDMA ATA 33/66/100 IDE ports on board

1 x FDD, 2 x COM(1 by cable), 1 x LPT, PS/2 Keyboard, PS/2 Mouse on board

1 x VGA(DB15), 1 x Joystick, 1 x Line-in, 1 x Line-out, 1 x MIC on board

4 x USB ports (2 front by optional cable and 2 rear by on-board connector)

IrDA header, front audio header, SPDIF header and SCR header

POWER

ATX power connector

Power-on by K/B, PS/2 Mouse, LAN, RTC, Modem and switch

Power-off by Windows® 95/98/2000/Me/XP shut down and switch

Supports USB device wake-up

Suspend / Wake-on by ACPI and APM device

AC recovery ON/OFF control; 3 level ACPI LED support

FORM FACTOR

Micro ATX, 4 layer PCB (24.4 x 20.4cm)

H/W MONITORING

Auto speed down and alarm when CPU overheat or fan failure (OS independent and driverless)

3 fan power and speed detection connectors; Case open detection

System health status detect and report by BIOS, LDCM®

H/W detect ∮5V, ∮12V, CPU voltage and CMOS battery status

BIOS

2Mbit flash RAM

BIOS with enhanced ACPI feature for PC99/Win98/Win2000/Me/XP compliance, Green, PnP, DMI, INT13 (>8.4GB) and Anti-Virus functions

IDE#1~#4, SCSI, LS120, ZIP and CD-ROM bootable

Supports @BIOS Live Update

Auto-detect and report system health status

OTHER FEATURES

Includes Wake-On-LAN header (WOL); Includes Wake-On-Ring (WOR)

Poly fuse for keyboard, USB and game overcurrent protection

With Kinnereth layout (Kinnereth chip is optional)

Supports Gigabyte EasyTune III™

DRIVER

Gigabyte Windows Utility Manager

Intel® LDCM® utility
