VIA Apollo KLE133 AGPset

PROCESSOR

Socket A for AMD Athlon™/Athlon™ XP/Duron™ 200/266 MHz FSB processors

Supports 500MHz ~ 2000+ and faster

Auto-detects CPU voltage

CHIPSET

VIA 8361 (KLE133) North Bridge

VIA 686B South Bridge

Realtek 8100 10/100Mb LAN chip

AC97 codec

MEMORY

Supports PC-100 / PC-133 SDRAM

Supports up to 2GB DRAM memory

2DIMMs of 168-pin DIMM sockets

CONNECTOR

1 x CNR (Communication Networking Riser) slot

3 x PCI slots support 33Mhz & PCI 2.2 compliant

2 x USB, 1 x COM, 1 x LPT, PS/2 Keyboard, PS/2 Mouse and 1xVGA out on rear side

2 x ATA 66/100 bus master IDE ports on board

1 x FDD, 2xHDD and 1xCD Audio Input on board

IrDA(1x5) and COM2 on board

1xRJ45 LAN port on board

Intel® Standard Front Panel and 2x Front USB Port on board

POWER/b>

ATX 20-pin power connector

Power-off by Windows® 98/ ME/ 2000/ NT/ XP shut down and Switch

FORM FACTOR

Micro ATX and 4 layers PCB (24.4 x 21.5 cm)

H/W MONITORING

System health status auto-detect and report by BIOS

H/W detect & report Power-in voltage, CPU voltage

Stop CPU fan when entering suspend to RAM mode

CPU/System fan revolution & temperature detect

BIOS

2Mbit flash ROM

IDE#1~#4, SCSI, LS120, ZIP and CD-ROM bootable

Supports @BIOS™ Live Update utility

Auto-detect and report system health status

AMI BIOS with enhanced ACPI feature for PC98/Win98/Win2000/ME/XP compliance

AC recovery ON/OFF control

OTHER FEATURES

Suspend-To-RAM (STR)

Supports EasyTune III™, @BIOS™ and Q-Flash™

Face Wizard™

DRIVER

VIA 4-in-1 service pack utility

Gigabyte Windows Utility Manager

RealTek LAN driver

*There speed settings are not guaranteed by GIGABYTE.

The specifiction and pictures are subject to change without notice.
