CPU

* Supports Intel® Pentium® 4 processor in 478 pin package.

* Supports 1.5 ~ 2.53GHz and up.

Chipset

Intel® 845E (593 FC-BGA) Chipset

- Support 400/533 MHz Intel®NetBurst micro-architecture bus

- Support AGP 4x slot (1.5V only)

- Support 100/133MHz FSB

Intel® ICH4 (360BGA) Chipset

- 2 full IDE channels, up to ATA 100

- AC'97 Controller Integrated

- Low pin count interface for SIO

FSB

- Support 100/133MHz FSB

- Support 400/533MHz Intel NetBurst micro-architecture bus

Main Memory

* Support max. of 2 double-sided DIMMs with unbuffered

DDR 200/266

* The largest memory capacity possible is 2GB

Slots

* One AGP (Accelerated Graphics Port) 4x slot (1.5V only)

* Six PCI 2.2v 32-bit Master PCI bus slots

* One CNR (Communication Network Riser) slot

On-Board IDE

* An IDE controller on the ICH4 chipset provides IDE HDD/

CD-ROM with PIO, Bus Master and Ultra DMA66/100

operation modes

* Can connect up to four IDE devices.

Audio

* ICH4 chip integrated (Optional)

- AC'97 codec supports 2 channel Audio (Realtek ALC202A)

Network

ICH4 chipset Onboard Intel LAN (Optional)

- ICH4 + 82562ET Integrated

On-Board Peripherals

On-Board Peripherals include:

- 1 floppy port supports 2 FDD with 360K, 720K, 1.2M, 1.44M

and 2.88Mbytes

- 2 serial ports (COM A + COM B)

- 1 parallel port supports SPP/EPP/ECP mode

- 6 ports USB 2.0 (Rear x 2 / Front x 4)

- 1 Line-In/Line-Out/Mic-In/Game port

BIOS

* The mainboard BIOS provides "Plug & Play" function which

detects the peripherals devices and expansion cards of the

board automatically

* The mainboard provides a Desktop Management Interface

(DMI) function which records your mainboard specifications

Dimension

30.5 cm(L) x 20.0 cm(W) ATX Form Factor

Mounting

6 mounting holes.
