Feature Highlights: Reads Single and Dual Layer DVD-ROM, DVD-Video discs plus DVD-R, CD-ROM, CD-R and audio CDs High data transfer rate: DVD-ROM: 2X - 6X 8.1 MB/s, CD-ROM: 14X - 32X 4.8 MB/s High speed average access time: DVD-ROM: 110 ms, CD-ROM: 80 ms High speed average seek time: DVD-ROM: 90 ms, CD-ROM: 75 ms SCSI-2 interface (with SCAM support)

Specifications

General
Supported Disc Formats	DVD-ROM, DVD-Video, DVD-R, CD-ROM, CD-R, CD-DA
Media Diameter	120 mm / 80 mm
Media Handling	Slot-In loading mechanism
Interface	SCSI-2
Data Block Size	2048 Bytes / 512 Bytes
Disc Startup Time	max. 3 seconds
Disc Spin Down Time	max. 3 seconds
Mean Time Between Failure	100,000 Power On Hours / 20% Duty
Data Transfer Rate (Sustained)	3.3 - 8.1 MB/s (2X - 6X)
Data Transfer Rate (Burst)	10 MB/s
Average Random Seek Time	90 ms
Average Random Access Time	110 ms
Data Buffer Capacity	512 KB
Data Transfer Rate (Sustained)	2.1 - 4.8 MB/s (14X - 32X)
Data Transfer Rate (Burst)	10 MB/s
Average Random Seek Time	75 ms
Average Random Access Time	80 ms
Data Buffer Capacity	128 KB
Headphone Connector	Stereo Mini-Jack
Output Level	0.7 ?0.1 Vrms (Line Out)
Frequency Response	17 ~ 20000 Hz (? dB)
Total Harmonic Distortion	0.1% or less
Physical Characteristics
Dimensions (W x H x D)	146 x 41.3 x 202.5 mm
Operating Voltage	+ 12V, + 5V
Net Weight	1.0 kg
Environmental Conditions
Operating Temperature	5癈 to 45癈
Operating Humidity (non-condensing)	5 to 85% RH
Storage Temperature	-20癈 to 60癈
Storage Humidity (non-condensing)	5 to 90% RH

■ 平均访问时间： DVD－ROM：120毫秒，CD－ROM：90毫秒
通过增强DVD－A05S的整体性能，使得它能迅速地访问特定的数据区域。当读取DVD－ROM时，随机访问时间仅为120毫秒。同时，扫描低密度的CD－ROM时，访问速度为90毫秒。

■ 插入式光碟的机械装置（同时提供托盘结构的型号）
先锋采用插入式光碟机械装置，一方面避免光碟的损坏，也便于用户水平或垂直安装驱动器。这种机制，能方便地读取光碟两面，避免接触数据面。另外，弹出光碟的时候，用户可以抓取裸露出来的光碟中心圆孔，从而避免手指碰到数据部分。

■ 能够读取单层和双层的DVD－ROM／DVD视盘碟，DVD－R，CD－ROM光碟，CD唱片，CD－R／RW，VCD，PHOTO CD，HYBRID CD，CD－EXTRA（加强型CD）
